| Qingdao Tangyu 3.5T rear steering four-wheel drive off-road forklift parameters | |
Rated Load(kg) | 3500 |
Max.unloading Height(mm) | Customizable multi-level door frame（3000-6000mm） |
Owerall Weight(kg) | 4450 |
Dimensions(mm) | 3650×1800×2450mm |
Max.Grade Ability | ≤35° |
Drive mode | Full-time four-wheel drive |
Front Wheel tires | 23.5/70-16 |
Rear Wheel tires | 23.5/70-16 |
Portal-frame Bottom(mm) | 240 |
Wheelbase center ground ciearance(mm) | 280 |
Wheelbase(mm) | 1940 |
Min.Turning Radius(mm) | 2500 |
Engine Model | 490 Country II/493 Country IV |
Engine power(kw) | 36.8-58kw |
Battery voltage/capacity | 24/60 |
Mast tilt angle (front/rear) | 6°/12° |
How many units can be loaded in a container | 3units |
